ASTM A182 SS Weld neck flange
ASTM Stainless Steel Plate Flanges
Stainless Steel Screwed Flanges
- What is Stainless Steel Flange?
- Stainless Steel Flanges Detailed Information
- Standard Specification of Stainless Steel Flanges
- Types of Stainless Steel Flanges We Manufactures
- About ASTM A105 Stainless Steel Flanges
- Stainless Steel Flanges sizes
- SS Flange Thickness Chart
- Blind Flange Weight Chart in Kg
- Stainless Steel Flange Pressure Ratings
- Stainless Steel Flanges Chemical & Mechanical Composition
- Materials of Stainless Steel Flange
- Documentation and Packing of Stainless Steel Flanges
- Applications of Stainless Steel Flanges in Industries
- Other Types of ASME B16.5 Flanges
- SS Flanges Export Network
- SS Flanges Supplier in India
ANSI 150 Stainless Steel Flange, ANSI 150 Stainless Steel Flange, ASTM A182 Weld Neck Flange, Stainless Steel Flanges, Stainless Steel 304H Flanges, SS Pipe Flange Manufacturer in Mumbai, India
Pearl Pipe Fittings is an eminent Stainless Steel Flange manufacturer in India. Through innovative hot and cold rolling technology we provide Stainless Steel flanges with improved strength alongside exact dimensions and perfect final appearance. Quality testing of our flanges combines chemical analysis with mechanical testing and hydro testing and non-destructive testing (NDT) to verify their performance abilities and durability and corrosion resistance before critical applications usage.
Best Quality ASTM A182 F316L SS Blind Flange Manufacturers, SS ASTM A182 Nipo flange, PN16 Stainless Steel Flanges Supplier and Exporter in India
Pearl Pipe Fittings is a leading Stainless Steel Flange supplier in India. Our stainless steel flanges result from modern hot and cold rolling manufacturing methods which produce flange items with strong components and precise dimensions and smooth finishes. To guarantee optimal corrosive and high-pressure performance all products endure rigorous quality exams consisting of chemical makeup examination and non-damaging inspections and mechanical durability assessment. We are well-known Carbon Steel IS 2062 manufacturer in India.
Specifications Of Stainless Steel Flange
AN ISO certified Stainless Steel Flange, compare our price with other SS flanges manufacturers in India.
| Specifications | ASTM A105 / ASME SA105, A105N |
| Standard | ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc. |
| Size | 1/2″ to 48″ |
| Dimensions | ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc. |
| Flanges Face Type | Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ), Lap-Joint Face |
| Class / Pressure | 150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc. |
SS Flange Manufacturer in India at lowest Price - Common Types of Stainless Steel Flanges
Pearl Pipe Fittings is a SS 304 Flange Manufacturers in India as per customer size and thickness, call now to get a quick quote.
.jpg "ASME SA182 Stainless Steel Blind Flange")
.jpg "Stainless Steel ASTM A182 Slip-On Flange")
Manufacturer of Stainless Steel Slip-on Flange, Stainless Steel Flanges Price List in Mumbai, ASTM A182 SS Plate Flange Manufacturers in India
Pearl Pipe Fittings is one of the largest Stainless Steel Pipe Flange Manufacturers and Supplier in India. Being one of the international suppliers of ASTM A182 150 Stainless Steel Flanges, we have a stock range of 1/2” NB to 24” NB SS Flanges and we can also supply 36” NB stainless steel flanges and for other increased sizes we can customize it as per international standards. Stainless steel forged flanges connect two pieces of machinery together, which can be added to a structure to make the object stronger and can be used in plumbing and mechanical fields.
Stainless Steel Flange Size Chart
| Size | Pressure Class | International Standard |
| 1/2″ To 48″ | 150 lb to 2500 lb | Australian flange |
| 1/2″ To 80″ | 150 lb to 300 lb | Korean flange |
| 3/8 to 60″ | 150 lb to 2500 lb | Japanese standard flange |
| 1/2″ To 48″ | PN6 To PN40 | DIN flange |
| 3/8″ to 80″ | PN 2.5 to PN 400 | EN 1092-1/2 |
| 26″ To 48″ | 150 lb to 600 lb | BS 3293 |
| 22″ To 48″ | 150 lb to 900 lb | MSS SP 44 |
| 4″ To 144″ | Class B/D/E/F | Awwa C207 |
| 2 1/2″ To 24″ | – | ISO flange |
| 1/4″ to 24″ | 150 lb to 2500 lb | ASME B16.5 |
| 1/4″ to 24″ | 300 lb to 2500 lb | ASME B16.36 |
| 26″ to 60″ | 150 lb to 900 lb | ASME B16.47 |
| 1/4″ to 24″ | 150 lb to 2500 lb | ASME B16.48 |
Thickness of SS Flanges
| SCH 10 | SCH 20 |
| SCH 30 | STD Wall |
| SCH 40 | SCH 60 |
| EXT Hvy | SCH 80 |
| XX Hvy | – |
| SCH 140 | SCH 160 |
| SCH 100 | SCH 120 |
Blind Flange Weight Chart in Kg
| NPS in inch | Class 150 | Class 300 | Class 400 | Class 600 |
| 1/2 | .9 | .9 | .9 | 1.4 |
| 3/4 | .9 | 1.4 | 1.4 | 1.8 |
| 1 | .9 | 1.8 | 1.8 | 1.8 |
| 1¼ | 1.4 | 2.7 | 2.7 | 2.7 |
| 1½ | 1.8 | 3.2 | 3.6 | 3.6 |
| 2 | 2.3 | 3.6 | 4.5 | 4.5 |
| 2½ | 3.2 | 5.4 | 6.8 | 6.8 |
| 3 | 4.1 | 7.2 | 9 | 9 |
| 3½ | 5.9 | 9.5 | 13 | 13 |
| 4 | 7.7 | 12.6 | 14.9 | 18.5 |
| 5 | 9 | 16.7 | 19.8 | 3 .6 |
| 6 | 12.2 | 22.5 | 27.5 | 38.7 |
| 8 | 21.2 | 36.5 | 45 | 63 |
| 10 | 31.5 | 55.8 | 69.8 | 103 |
| 12 | 55.4 | 83.3 | 101.7 | 132.8 |
| 14 | 63 | 112.5 | 139.5 | 17 .1 |
| 16 | 81 | 141.8 | 179.1 | 237.2 |
| 18 | 99 | 186.3 | 225.9 | 299.3 |
| 20 | 128.3 | 231.8 | 279.5 | 384.8 |
| 22 | 159.8 | 288 | 324 | 450 |
| 24 | 193.5 | 360 | 421.2 | 562.5 |
Stainless Steel Flanges Pressure Ratings
| ANSI/ASME B16.34 | PRESSURE RATING CHART | ||||||
| Temperature °F | 150# | 300# | 400# | 600# | 900# | 1500# | 2500# |
| -20 to 100 | 275 | 720 | 960 | 1440 | 2160 | 3600 | 6000 |
| 200 | 230 | 600 | 800 | 1200 | 1800 | 3000 | 5000 |
| 300 | 205 | 540 | 720 | 1080 | 1620 | 2700 | 4500 |
| 400 | 190 | 495 | 660 | 995 | 1490 | 2485 | 4140 |
| 500 | 170 | 465 | 620 | 930 | 1395 | 2330 | 3880 |
| 600 | 140 | 435 | 580 | 875 | 1310 | 2185 | 3640 |
| 650 | 125 | 430 | 575 | 860 | 1290 | 2150 | 3580 |
| 700 | 110 | 425 | 565 | 850 | 1275 | 2125 | 3540 |
| 750 | 95 | 415 | 555 | 830 | 1245 | 2075 | 3460 |
| 800 | 80 | 405 | 540 | 805 | 1210 | 2015 | 3360 |
| 850 | 65 | 395 | 530 | 790 | 1190 | 1980 | 3300 |
| 900 | 50 | 390 | 520 | 780 | 1165 | 1945 | 3240 |
| 950 | 35 | 380 | 510 | 765 | 1145 | 1910 | 3180 |
| 1000 | 20 | 320 | 430 | 640 | 965 | 1605 | 2675 |
| 1050 | 20 | 310 | 410 | 615 | 925 | 1545 | 2570 |
| 1100 | 20 | 255 | 345 | 515 | 770 | 1285 | 2145 |
| 1150 | 20 | 200 | 265 | 400 | 595 | 995 | 1655 |
| 1200 | 20 | 155 | 205 | 310 | 465 | 770 | 1285 |
| 1250 | 20 | 115 | 150 | 225 | 340 | 565 | 945 |
| 1300 | 20 | 85 | 115 | 170 | 255 | 430 | 715 |
| 1350 | 20 | 60 | 80 | 125 | 185 | 310 | 515 |
| 1400 | 20 | 50 | 65 | 95 | 145 | 240 | 400 |
| 1450 | 15 | 35 | 45 | 70 | 105 | 170 | 285 |
| 1500 | 10 | 25 | 35 | 55 | 80 | 135 | 230 |
| Type | Carbon | Manganese | Phosphorus | Sulphur | Silicon | Chromium | Nickel | Molybdenum |
| 304* | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 18.00/20.00 | 8.00/10.50 | – |
| 304L* | 0.03 | 2.00 | 0.045 | 0.030 | 1.00 | 18.00/20.00 | 8.00/12.00 | – |
| 317 | 0.08 | 2.00 | 0.045 | 0.030 | 1.00/1.00 | 18.00/20.00 | 11.00/15.00 | 3.00/4.00 |
| 316* | 0.08 | 2.00 | 0.045 | 0.030 | 1.00 | 16.00/18.00 | 10.00/14.00 | 2.00/3.00 |
| 310 | 0.25 | 2.00 | 0.045 | 0.030 | 1.5 | 24.00/26.00 | 19.00/22.00 | – |
| 316L* | 0.03 | 2.00 | 0.045 | 0.030 | 1.00 | 16.00/18.00 | 10.00/14.00 | 2.00/3.00 |
| 321 | 0.08 | 2.00 | 0.040 | 0.030 | 1.00 | 17.00/19.00 | 9.00/12.00 | 0.75/0.75 |
| Type | UNS | Tensile (ksi) min |
Yield (ksi) min |
Elongation min |
Hardness (Brinell) max |
Hardness (Rockwell B) max |
| 304* | S30400 | 75 | 30 | 40% in 2″ | 183 | 88 |
| 304L* | S30403 | 70 | 30 | 40% in 2″ | 183 | 88 |
| 310 | S31000 | 75 | 30 | 40% in 2″ | 217 | 95 |
| 316* | S31600 | 75 | 30 | 40% in 2″ | 217 | 95 |
| 316L* | S31603 | 70 | 25 | 35% in 2″ | 217 | 95 |
| 317 | S31700 | 75 | 30 | 35% in 2″ | 217 | 95 |
| 317L | S31703 | 75 | 30 | 35% in 2″ | 217 | 95 |
| 321 | S32100 | 75 | 30 | 40% in 2″ | 183 | 88 |
Standards of Stainless Steel Flange
ASME B16.47 Pipe SS Flanges
ASME B16.5 Chromium Nickel Stainless Steel Flange
ASME B16.45 Martensitic Stainless Steel grade Flanges
ASME B16.36 Ferritic Stainless Steel grade Pipe Flange
ASTM A182 SS Steel Pipe Flange
ASME B16.5 Chromium Nickel Stainless Steel Flange
Uses of Stainless Steel Flange
- Boiler Applications
- Railway Industry
- Chemical Industry
- Hydrogen Gas Plant
- Sugar Mills
- Paper Mills
- Nuclear Power Plant
- Oil and Gas Exporations
- Commercial Invoice which includes HS Code Of SS Flanges
- Packing List including net weight and gross weight, number of boxes, Marks and Numbers
- Certificate of Origin legalized/attested by Chamber of Commerce or Embassy
- Packaging done Export worthy in plywooden case or wooden box
Pearl Pipe Fittings is one of the most largest Stainless Steel Flanges Manufacturers in india.
| ANSI 150 Stainless Steel Flanges Products | |
| DIN2576 A182 SOFF Flange PN10 DN25 | ASME B16.5 A182 WNRF Flange DN40 SCH40S PN16 |
| Stainless Steel Split Flanges | ASME B1.20.1 Class 300 Metric Stainless Steel Flanges |
| Stainless Steel CF (ConFlat) Flanges | Stainless Steel Exhaust Flanges |
| ASME B16.5 High Pressure Stainless Steel Flanges | Super Ferritic Stainless Steel SORF Flange |
| Super Austenitic Stainless Steel Spades & Ring Spacers | Austenitic Stainless Steel Ring Type Joint Flanges |
| AWWA Stainless Steel Flanges Standards | Stainless Steel Flanges PN25 Standards Flanges |
| PN10 Stainless Steel Flanges | A182 Stainless Steel Raised Face Flanges |
| ANSI B16.5 ASTM A182 SS BLIND FLANGE RTJ 2 INCH SCH80 CL900 | ASME B16.5 A182 Stainless Steel WNRF Flange 4 Inch SCH40S |
| ASME B16.5 A182 Stainless Steel WNRF Flange DN250 SCH100 | 150# Stainless Steel Flanges |
| ASTM A182 Stainless Steel Blind Flange | SAE Stainless Steel Weld Flange |
